SPESIFIKASI
POWER SUPPLY 8 – 32 VDC
INTERNAL BATTERY RECHARGE VOLTAGE 10 – 32 VDC, built-in 7.4 V, 1Ah lithium battery
BATTERY AUTONOMY up to 5 hours
MAXIMUM CURRENT DRAW 1,2 A at 12 V
ENVIRONMENTAL
Operating temperature: 0 ÷ +45°C
Storage temperature: – 20 °C ÷ 60 °C
Operating relative humidity: 10 % ÷ 80 % non-condensing
DIMENSIONS
155x178x55 mm (excluding Bluetooth antenna)
WEIGHT
1,2 kg.
OSCILLOSCOPE CHANNELS
4 independent input channels with analogue bandwidth of 10 MHz (-3 dB); sampling rate 20MSamples/sec at 10 bit with 1 or 2 channels active, 10 MSamples/sec at 10 bit with 3 or 4 channels active
MAX INPUT VOLTAGE
+/- 50 Vmax, AC or DC couplingbr
VERTICAL SCALE FOR EACH CHANNEL
from 20 mV/Div to 50 V/Div
HORIZONTAL SCALE
from 500 ns/Div to 5s/Div
TRIGGER
source CH1, CH2, CH3, CH4, selectable, trigger delay.
DISPLAY MODE
Normal, Auto, Single shot
